<p>The Spherical Contact Shims set can be installed in the rear ball joint (ST1209M) instead of the OR125 O-ring.</p>
<p>The SS3x4 screw in the Battery plate is not needed at thus and should be removed.</p>
<p>This Contact Shims prevent vertical movement in other directions but allows swing and rotation.</p>
<p>Benefits of SCS set: <br>
- smooth and consistent operation without the need of further re-adjustments like it's normal with the SS3X4 screw use.<br>
- no any scratching of AM1204 chassis surface.</p>
<p>INSTALLATION AND ADJUSTMENT<br>
Even tiny tolerances of the SCS set itself and also the surrounded parts can lead to A) binding or B) too much free play.</p>
<p>A) Sand the lower surface of ST1225 very gently to remove 0,03mm<br>
B) Use thin tape (0,0Xmm) or 0,05mm shim (6x8mm) under ST1225.<br>
TIP: Attach a small piece of tape first on AM1204 and cut the round hole via RC knife using the existing 6mm hole in AM1204 as a guide.<br>
Then place the cutted piece of tape on AM1203.</p>
<p>Contains<br>
1x ST1225 - Spherical Pad<br>
1x ST1224 - Spherical Washer</p>
